उत्पाद विवरण:
|
| Product name: | KSD301 Thermostat 16A 125V | Working Temperature: | 0~260 ℃ |
|---|---|---|---|
| OEM: | Accepted | Function: | Momentary , Normally Close |
| Housing Material: | Bakelite | Cover: | fixed/ moveable/ screw |
| Insulation resistance: | ≥100MΩ(DC500V) | Free Sample: | Available |
| प्रमुखता देना: | Momentary KSD301 Thermostat,Bent Terminal KSD301 Thermostat,16A KSD301 Bimetal Thermostat |
||
Bimetal Bent Terminal Momentary KSD301 Thermostat 16A 125V
Product Description
KSD301-R bimetallic thermostat is a kind of miniature hermetically sealed bimetal temperature limiter (1/2" disc). It is of single-pole single-throw structure and works under resistive load. This safety limiter is in wide use in a great variety of compact type home appliances, such as coffee maker, water dispenser, toaster, microwave oven, electric pad and portable icebox etc., to provide temperature control or temperature protection.
Parameter
| Use | Temperature control/Overheat protection |
| Appliance | Coffee maker/ Drinking machine/toaster/Microwave oven/ Heating/ Portable Refrigerator/etc |
| Reset type | Manual |
| Base material | resist heat resin base |
| Amperage | 5A/10A/16A |
| Max. Operating Temperature | 180°C |
| Differential | Refer to the regulation |
| Tolerance | Refer to the regulation |
| Protection class | IP00 |
| Contact material | Silver/Gold |
| Dielectric Strength | Parts between electriferous components and non-electriferous ones can bear 2000V (3750V for Reinforced insulation type) 50Hz AC current, which is nearly sine wave, for one minute as bearing test. Resulted no breakdown, no flashover. |
| Insulation Resistance | With a DC 500V megger, borne DC 500V, the tested value is over 10MW. |
| Resistance Between Terminals | Below 50mW |
| Temp. characteristics |
Normal type: OFF temperature higher than ON temperature.(Normal close) One-shot type: The thermostat switches on at room temperature and it won’t be able to reset after switching off. |
|
Maximum ambient temperature |
205°C(Long period) 235°C (Less than 15 min) |
| Diameter of bimetal disc | F12.8mm(1/2″) |
| Approvals | UL/CQC/TUV |
| Terminal type | Customized (Refer to our specification) |
| Cover/Bracket |
Customized (Refer to our specification) |
Open temperature & reset temperature
1. According to customer’s request to set the open temperature and reset temperature.
2. The standard open temperature and reset temperature’s sheet for auto reset type as below
|
Open Temp. |
Reset Temp. |
Open Temp. |
Reset Temp. |
Open Temp. |
Reset Temp. |
|
-20℃+-5℃ |
5℃+-5℃ |
95℃+-5℃ |
80℃+-5℃ |
205℃+-5℃ |
175℃+-10℃ |
|
-15℃+-5℃ |
5℃+-5℃ |
100℃+-5℃ |
80℃+-10℃ |
210℃+-5℃ |
180℃+-10℃ |
|
-10℃+-5℃ |
5℃+-5℃ |
105℃+-5℃ |
85℃+-10℃ |
215℃+-5℃ |
185℃+-10℃ |
|
0℃+-5℃ |
-10℃+-5℃ |
110℃+-5℃ |
90℃+-10℃ |
220℃+-5℃ |
190℃+-10℃ |
|
5℃+-5℃ |
-5℃+-5℃ |
115℃+-5℃ |
95℃+-10℃ |
225℃+-5℃ |
195℃+-10℃ |
|
10℃+-5℃ |
0℃+-5℃ |
120℃+-5℃ |
100℃+-10℃ |
230℃+-5℃ |
200℃+-10℃ |
|
15℃+-5℃ |
5℃+-5℃ |
125℃+-5℃ |
105℃+-10℃ |
235℃+-5℃ |
205℃+-10℃ |
|
20℃+-5℃ |
5℃+-5℃ |
130℃+-5℃ |
110℃+-10℃ |
240℃+-5℃ |
210℃+-10℃ |
|
25℃+-5℃ |
10℃+-5℃ |
135℃+-5℃ |
115℃+-10℃ |
245℃+-5℃ |
215℃+-10℃ |
|
30℃+-5℃ |
15℃+-5℃ |
140℃+-5℃ |
120℃+-10℃ |
250℃+-5℃ |
220℃+-10℃ |
|
35℃+-5℃ |
20℃+-5℃ |
145℃+-5℃ |
125℃+-10℃ |
255℃+-5℃ |
225℃+-10℃ |
|
40℃+-5℃ |
25℃+-5℃ |
150℃+-5℃ |
130℃+-10℃ |
260℃+-5℃ |
230℃+-10℃ |
|
45℃+-5℃ |
30℃+-5℃ |
155℃+-5℃ |
130℃+-10℃ |
265℃+-5℃ |
235℃+-10℃ |
|
50℃+-5℃ |
35℃+-5℃ |
160℃+-5℃ |
135℃+-10℃ |
270℃+-5℃ |
240℃+-10℃ |
|
55℃+-5℃ |
40℃+-5℃ |
165℃+-5℃ |
140℃+-10℃ |
275℃+-5℃ |
245℃+-10℃ |
|
60℃+-5℃ |
45℃+-5℃ |
170℃+-5℃ |
145℃+-10℃ |
280℃+-5℃ |
250℃+-10℃ |
|
65℃+-5℃ |
50℃+-5℃ |
175℃+-5℃ |
150℃+-10℃ |
285℃+-5℃ |
255℃+-10℃ |
|
70℃+-5℃ |
55℃+-5℃ |
180℃+-5℃ |
155℃+-10℃ |
290℃+-5℃ |
260℃+-10℃ |
|
75℃+-5℃ |
60℃+-5℃ |
185℃+-5℃ |
155℃+-10℃ |
295℃+-5℃ |
265℃+-10℃ |
|
80℃+-5℃ |
65℃+-5℃ |
190℃+-5℃ |
160℃+-10℃ |
300℃+-5℃ |
270℃+-10℃ |
|
85℃+-5℃ |
70℃+-5℃ |
195℃+-5℃ |
165℃+-10℃ |
|
|
|
90℃+-5℃ |
75℃+-5℃ |
200℃+-5℃ |
170℃+-10℃ |
|
|
The product UL,CQC,VDE and RoHS certification approval.
